UDPEndpoint Class Reference

Handles sending and receiving UDP-Packages. More...

#include <UDPEndpoint.h>

Inheritance diagram for UDPEndpoint:

[legend]Collaboration diagram for UDPEndpoint:

[legend]List of all members.

Public Member Functions
	UDPEndpoint (int sendBufferSize=2048, int receiveBufferSize=2048)
	~UDPEndpoint ()
int	bind (int listenPort)
	binds endpoint to listen to port
int	bind (int listenPort, char *address, int sendPort)
	binds endpoint to listen to port and sets receiving host to address:port
int	bind (Port listenPort, IPAddress address, Port sendPort)
int	send (int size)
	sends data from the shared buffer (does no copy of data and assumes that the Data is in sharedSendBuffer
int	send (int size, char *addr, int sPort)
	sends data from the shared buffer to a givern host/port
int	send (void *data, int size)
	sends data to last specified other host (copies the data)
int	send (void *data, int size, char *address, int port)
	sends data to other host
int	send (void *data, int size, IPAddress address, int port)
	sends data to other host
virtual void	onReceive (void *data, int size)
	Called when new data arrives.
virtual void	onClose ()
	Called from close() when connection closes.
virtual void	onSendingDone ()
void	close ()
	Closes Endpoint in case of an error.
const char *	getErrorString (UDPEndpointError error)
	gets errorString of error
const char *	getErrorString ()
	gets errorString of last error
virtual void	sendCont (antEnvMsg *msg)
	called by the framwork is sending is done
virtual void	receiveCont (antEnvMsg *msg)
	called by the framweok if there is new data
virtual void	closeCont (antEnvMsg *msg)
	does cleanup-stuff
Protected Attributes
IPAddress	ipOfLastPackage
	Ip of the last package recieved.
Private Member Functions
void	startReceiving ()
Private Attributes
IPAddress	address
	IP address to send the data to.
Port	sendPort
	port to send the data to
Port	listenPort
	port to listen for data

---

Detailed Description

Handles sending and receiving UDP-Packages.

Definition at line 17 of file UDPEndpoint.h.

---

Constructor & Destructor Documentation

UDPEndpoint::UDPEndpoint (  int  sendBufferSize = 2048, int  receiveBufferSize = 2048 )

Definition at line 16 of file UDPEndpoint.cpp.

UDPEndpoint::~UDPEndpoint (   )

Definition at line 33 of file UDPEndpoint.cpp. References close().

Here is the call graph for this function:

---

Member Function Documentation

int UDPEndpoint::bind (  int  listenPort  )

binds endpoint to listen to port Definition at line 39 of file UDPEndpoint.cpp. References getErrorString(), listenPort, and startReceiving(). Referenced by bind(), DDPHandler::initDDPHandler(), and UDPHandler::start().

Here is the call graph for this function:

int UDPEndpoint::bind (  int  listenPort, char *  address, int  sendPort )

binds endpoint to listen to port and sets receiving host to address:port Definition at line 65 of file UDPEndpoint.cpp. References bind(), and sendPort.

Here is the call graph for this function:

int UDPEndpoint::bind (  Port  listenPort, IPAddress  address, Port  sendPort )

Definition at line 56 of file UDPEndpoint.cpp. References bind(), and sendPort.

Here is the call graph for this function:

int UDPEndpoint::send (  int  size  )

sends data from the shared buffer (does no copy of data and assumes that the Data is in sharedSendBuffer Definition at line 82 of file UDPEndpoint.cpp. References sendPort. Referenced by send(), DDPHandler::sendDDPPackage(), and UDPHandlerEndpoint::sendPackage().

int UDPEndpoint::send (  int  size, char *  addr, int  sPort )

sends data from the shared buffer to a givern host/port Definition at line 90 of file UDPEndpoint.cpp. References send(), and sendPort.

Here is the call graph for this function:

int UDPEndpoint::send (  void *  data, int  size )

sends data to last specified other host (copies the data) Definition at line 74 of file UDPEndpoint.cpp. References send().

Here is the call graph for this function:

int UDPEndpoint::send (  void *  data, int  size, char *  address, int  port )

sends data to other host Definition at line 99 of file UDPEndpoint.cpp. References send(), and sendPort.

Here is the call graph for this function:

int UDPEndpoint::send (  void *  data, int  size, IPAddress  address, int  port )

sends data to other host Definition at line 107 of file UDPEndpoint.cpp. References send(), and sendPort.

Here is the call graph for this function:

void UDPEndpoint::onReceive (  void *  data, int  size )  [virtual]

Called when new data arrives. Reimplemented in DDPHandler, and UDPHandlerEndpoint. Definition at line 134 of file UDPEndpoint.cpp. Referenced by receiveCont().

void UDPEndpoint::onClose (   )  [virtual]

Called from close() when connection closes. Definition at line 173 of file UDPEndpoint.cpp. Referenced by close().

void UDPEndpoint::onSendingDone (   )  [virtual]

Reimplemented in UDPHandlerEndpoint. Definition at line 130 of file UDPEndpoint.cpp. Referenced by sendCont().

void UDPEndpoint::close (   )

Closes Endpoint in case of an error. Definition at line 164 of file UDPEndpoint.cpp. References onClose(). Referenced by ~UDPEndpoint().

Here is the call graph for this function:

const char * UDPEndpoint::getErrorString (  UDPEndpointError  error  )

gets errorString of error Definition at line 184 of file UDPEndpoint.cpp.

const char* UDPEndpoint::getErrorString (   )

gets errorString of last error Referenced by bind(), receiveCont(), and sendCont().

void UDPEndpoint::sendCont (  antEnvMsg *  msg  )  [virtual]

called by the framwork is sending is done Reimplemented from IPEndpoint. Definition at line 115 of file UDPEndpoint.cpp. References getErrorString(), and onSendingDone().

Here is the call graph for this function:

void UDPEndpoint::receiveCont (  antEnvMsg *  msg  )  [virtual]

called by the framweok if there is new data Actually calls onReceive() Reimplemented from IPEndpoint. Definition at line 149 of file UDPEndpoint.cpp. References getErrorString(), ipOfLastPackage, onReceive(), and startReceiving().

Here is the call graph for this function:

void UDPEndpoint::closeCont (  antEnvMsg *  msg  )  [virtual]

does cleanup-stuff Reimplemented from IPEndpoint. Definition at line 177 of file UDPEndpoint.cpp.

void UDPEndpoint::startReceiving (   )  [private]

Definition at line 140 of file UDPEndpoint.cpp. Referenced by bind(), and receiveCont().

---

Member Data Documentation

IPAddress UDPEndpoint::ipOfLastPackage [protected]

Ip of the last package recieved. Definition at line 65 of file UDPEndpoint.h. Referenced by receiveCont().

IPAddress UDPEndpoint::address [private]

IP address to send the data to. Definition at line 68 of file UDPEndpoint.h.

Port UDPEndpoint::sendPort [private]

port to send the data to Definition at line 69 of file UDPEndpoint.h. Referenced by bind(), and send().

Port UDPEndpoint::listenPort [private]

port to listen for data Definition at line 70 of file UDPEndpoint.h. Referenced by bind().

---

The documentation for this class was generated from the following files:

• Platform/Aperios1.3.2/UDPEndpoint.h
• Platform/Aperios1.3.2/UDPEndpoint.cpp

---
